Feature |
|
|
|
|
|---|---|---|---|---|
Scanner type |
Trimode(Blue Laser +LED + IR VCSEL | White LED + IR VCSEL | Hybrid Blue Laser + Blue LED | Infrared VCSEL structured light |
Accuracy |
Up to 0.04 mm; volumetric 0.04 + 0.06 mm/m | Up to 0.05 mm; volumetric 0.05 + 0.1 mm/m | Up to 0.04 mm; volumetric 0.04 + 0.06 mm/m | Up to 0.1 mm point-to-point |
Scan Speed |
Laser HD: 4.4 M pts/s; IR Rapid: 1.6 M pts/s | 1.2 M pts/s | 1.6 M pts/s, 120 FPS | 980k pts/s; up to 14 FPS |
Point Distance |
0.05–10 mm | 0.25–3 mm | 0.05–3 mm | 0.1–3 mm |
Field of View |
400 x 900 mm | 780 × 900 mm | 420 × 440 mm | 434 × 379 mm |
Working Distance |
170–1500 mm | 200–1500 mm | ~470 mm | 160–1400 mm |
Texture/Color |
5 MP texture camera | 5 MP texture camera | 1.3 MP texture camera | RGB color camera |
Alignment Modes |
Markers / Feature / Texture / Hybrid / Global | Feature / Texture / Marker | Feature / Texture / Marker | Feature / Texture / Hybrid / Global |
Portability |
Standalone, wireless, battery-powered | Handheld | Handheld | Handheld, lightweight |
Key Differentiator |
Standalone use, tri-mode laser, no PC needed | Ultra-wide FOV, body-friendly, Best for Texture piority object | High-speed + high-detail +High Accuracy scanning | Budget-friendly, IR safe, good for outdoor & shiny scans |
Output File Formats |
OBJ, STL, ASC, PLY | OBJ, STL, ASC, PLY | OBJ, STL, ASC, PLY | OBJ, STL, PLY |
Color Texture Mapping |
Yes | Yes | Yes | Yes |
Minimum Scan Volume |
~30 × 30 × 30 mm | ~100 x100 x 100 mm | ~50 × 50 × 50 mm | ~150 × 150 × 150 mm |
Max Object Size (Single Scan) |
>2 meters supported | Large objects (e.g. full body) upto 2-3 meter p | small -to-large parts | Medium size, not for large industrial parts |
Outdoor Scanning Support |
Moderate (if shaded) | Good (especially with IR), Best for heritage site | Good (laser better for reflective parts) | Very good (designed for general use including outdoors) |
Eye Safety Class |
Class 1 (Safe) | Class 1 (Safe) ,White LED (safe ) | Class 1 (Safe) | Class 1 (Safe) |
Software Included |
RIGIL Studio / EXScan | EXScan | EXScan | EinStar Software |
Operating System Compatibility |
Windows 10/11 | Windows 10/11 | Windows 10/11 | Windows 10/11 |
Precision metrology (tight tolerance, part validation) |
★★★★★ | ★★★☆☆ | ★★★★☆ | ★★☆☆☆ |
Reverse engineering + moderate metrology |
★★★★☆ | ★★★☆☆ | ★★★★★ | ★★☆☆☆ |
Scanning Human body or organic shapes (Viz Sculptures) |
★★★☆☆ | ★★★★★ | ★★★★☆ | ★★★☆☆ |
Budget visualization or education/Entry level use |
★★★☆☆ | ★★★☆☆ | ★★★☆☆ | ★★★★★ |
